The AET63 BioTRUSTKey combines the highly successful silicon fingerprint sensor with a smart card reader to achieve ultra-secure authentication. It is a fully-integrated fingerprint-based biometric subsystem,combining fingerprint sensing and algorithm processing in a single, compact device. All biometric algorithm processing is carried out in a custom chip integrated at the back of the silicon fingerprint sensor.

Our biometric products leverage ACS technology and experience in implementing readers in smart card-based authentication programs. By partnering with a leading biometric sensor and algorithm supplier, we are providing a high level of security and convenience for applications in the government, corporate, financial and healthcare sectors.

With BioTRUSTKey, you have all the hardware and software you need to add biometric security to your custom applications. For PC applications, the BioTRUSTKey provides the highest level of security. This is because both the template extraction and matching algorithms run within the device itself – not in the PC.

The BioTRUSTKey significantly reduces development time and cost. Therefore new product design can be validated quickly and accurately. With the simple Application Programming Interface (API) provided, designers can easily add fingerprint authentication and smart card features into their products/applications. A system can be developed very quickly even without an in-depth knowledge of biometrics.

  • Integrated fingerprint scanner and smart card reader
  • Low-speed USB interface
  • Requires no additional power supply
  • Smart card reader:
    • Supports all microcontroller cards, with T=0 or T=1 protocols
      • Supports ISO 7816 Class A, B and C (5V, 3V and 1.8V) cards
    • Fingerprint scanner:
    • Match-on reader: Template extraction and matching algorithms run within the device itself, not in the PC
    • UPEK large area fingerprint sensor
    • Large active sensor size – 12.8 mm x 18.0 mm
    • High-resolution 508 DPI imaging
    • Utilizes CMOS active capacitive pixel-sensing technology, resulting to high-quality fingerprint images in any environment
  • Encrypted fingerprint template stored inside smart card
  • Session key generation among smart card, BioTRUSTKey processor and host computer
  • USB data transmission protection via 3DES encryption
  • Optional SAM slot
    • e-Government
    • e-Banking  and e-Payment
    • e-Healthcare
    • Public Key Infrastructure
    • Network Security
    • Access Control
    • Loyalty Program

ACR38U-I1: 72.2mm (L) x 69.0mm (W) x 14.5mm (H)
ACR38U-H1: 71.5mm (L) x 80.0mm (W) x 80.0mm (H)
ACR38U-J1: 65.5mm (L) x 68.2mm (W) x 13.7mm (H)

1.5 Mbps (Low Speed)
Supply Voltage
Regulated 5V DC
Supply Current
Max. 50mA
Operating Temperature
CLK Frequency
4 MHz
Smart Card Interface Support
  • ISO- 7816 Class A, B and C ( 5V, 3V, 1.8V )
*For ACR38U-I1 only
  • PC/SC, CE, FCC, RoHS Compliant
  • Microsoft ® WHQL 2000, XP, Vista, 7
*For ACR38U-I1 only
Operating System Support
  • Win98, Win ME, Win NT 4.0, Win 2000, Win 2003, Win 2003 R2, Win XP, Win Vista, Win 2008, Win 7, Win 8
  • Win 2003 x64, Win 2003 R2 x64, Win XP x64, Win Vista x64, Win 2008 x64, Win 2008 R2 x64, Win 7 x64, Win 8 x64, Win 2012 x64
  • Mac
  • Linux
  • Android™ 3.1 and above
